CH530x1100
| Capacity | |
|---|---|
| Swing over bed | 532 mm |
| Swing over carriage | 368 mm |
| Swing over gap | 710 mm |
| Width of gap in front of face plate | 150 mm |
| Distance between centers ( A1 - 6, A2 - 6 ) | 767, 1067, 1667 mm ( A1 - 6, A2 - 6 ) |
| Width of bed | 300 mm |
| Stroke of tool post | 145 mm |
| Stroke of cross slide | 265 mm |
| Headstock | |
| Spindle bore | 58 mm ( 78 mm ) * |
| Taper of spindle bore & center | MT6 x MT4 |
| Number of spindle speeds | 12 |
| Spindle nose | A1 - 6, D1 - 6 ( A2 - 6 ) * |
| Spindle speed ( 60 HZ ) | ø 58 mm : 35, 52, 75, 110, 160, 230, 330, 490, 650, 950, 1350, 2000 rpm ø 78 mm : 29, 43, 62, 90, 130, 190, 275, 405, 540, 790, 1120, 1650 rpm |
| Threading & Feeds | |
| Number of feeds | 36 |
| Range of longitudinal feeds metric | 0.037 ~ 1.04 mm / rev ( P = 6 mm) 0.035 ~ 0.98 mm / rev ( 4 TPI ) |
| Range of cross feeds | Half of longitudinal feeds |
| Leadscrew diameter | 35 mm |
| Leadscrew pitch | 4 TPI , P = 6 mm |
| Range of inch pitches | 2 ~ 72 TPI ( 44 Kinds ) |
| Range of metric pitches | 0.2 ~ 14 mm ( 39 Kinds ) |
| Tailstock | |
| Quill stroke | 170 mm |
| Quill diameter | 60 mm |
| Quill taper | MT # 4 |
| Motor | |
| Main motor ( 30 min. ) | 5 HP ( 7.5 HP ) * |
| Coolant pump motor | 1 / 8 HP |
| Height | 1400 mm |
| Floor space | 2000, 2300, 2900 × 1000 mm |
| Weight | 1600, 1700, 1900 kgs |
